VIVOTEK FD8169 is an easy-to-use fixed dome network camera specifically designed for indoor security applications with a compact, stylish exterior. Equipped with a 2MP sensor enabling viewing resolution of 1920x1080 at a smooth 30 fps, the FD8169 is an all-in-one camera capable of capturing high quality and high resolution video up to 2 Megapixel.

In order to adapt to constantly changing lighting conditions, the FD8169 features a removable IR-cut filter as well as improved IR illuminators effective up to 15M for superior image quality around the clock. Featuring 3D Noise Reduction Technology, it enables the FD8169 to capture clear, polished video under low-light conditions, which also helps to reduce bandwidth from sensor noise.

The FD8169 supports the industry-standard H.264 compression technology, drastically reducing file sizes and conserving valuable network bandwidth. With H.264, and MJPEG compatibility both included, multiple streams can be simultaneously transmitted in any of these formats at different resolutions, frame rates, and image qualities for versatile platforms. Thereby it further optimizes bandwidth and storage efficiency.

Incorporating a number of advanced features standard for VIVOTEK cameras, including tamper detection, 802.3af compliant PoE, MicroSD/SDHC/SDXC card slot, and VIVOTEK's 32-channel recording software, the FD8169 is the ideal solution for your indoor surveillance needs.

Feature

  • 2-Megapixel CMOS Sensor
  • 30 fps @ 1920x1080
  • Removable IR-cut Filter for Day & Night Function
  • Built-in IR Illuminators, Effective up to 15 Meters
  • Built-in 802.3af Compliant PoE
  • Build-in MicroSD/SDHC/SDXC Card Slot for On-board Storage
  • Supports ONVIF Standard to Simplify Integration and Enhance Interoperability
  • 3D Noise Reduction
  • Smart IR Technology to Avoid Overexposure
  • WDR Enhancement for Unparalleled Visibility in Extremely Bright and Dark Environments
  • CPU
    • Multimedia SoC (System-on-Chip)
    Flash
    • 128 MB
    RAM
    • 256 MB
    Image sensor
    • 1/2.7" progressive CMOS
    Maximum Resolution
    • 1920x1080
    Lens Type
    • Fixed-focal
    Focal Length
    • f = 2.8 mm
    • f = 3.6 mm (FD8169-F3)
    Aperture
    • F2.0
    Field of View
    • FD8169:
      • 105° (horizontal)
      • 87° (vertical)
      • 135° (diagonal)
    • FD8169-F3:
      • 93° (horizontal)
      • 50° (vertical)
      • 116° (diagonal)
    Shutter Time
    • 1/5 sec. to 1/32,000 sec.
    WDR Techonolgy
    • WDR Enhanced
    Day & Night
    • Removeable IR-cut filter for day & night function
    Minimum Illumination
    • 1.22 Lux @ F2.0
    • 0.008 @ F2.0
    • 0 Lux @ IR LED ON
    Pan range
    • 348°
    Tilt range
    • 70°
    Rotation Range
    • 345°
    Pan / Tilt / Zoom
    • ePTZ
    • 48x digital zoom ( 4x on IE plug-in, 12x built-in )
    IR Illuminators
    • Built-in illuminators, effect up to 15 meters with Smart IR
    • IR LED*6
    On-board Storage
    • MicroSD/SDHC/SDXC card slot
    Compression
    • H.264 & MJPEG
    Maximum Frame Rate
    • 30 fps @ 1920x1080 in both compression
    Maximum Streams
    • 3 simultaneous streams
    S/N Ratio
    • Above 53 dB
    Dynamic Range
    • 54.5 dB
    Video Streaming
    • Adjustable resolution, quality and bitrate
    • Configurable video cropping for bandwidth saving
    Image Settings
    • Adjustable image size, quality and bit rate
    • Time stamp, text overlay, flip & mirror
    • Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks
    • Scheduled profile settings, 3D Noise Reduction
    Users
    • Live viewing for up to 10 clients
    Protocols
    • IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP
    Interface
    • 10Base-T/100 BaseTX Ethernet (RJ-45)
    ONVIF
    • Supported, specification available at www.onvif.org
    Video Motion Detection
    • Triple-window video motion detection
    Alarm Triggers
    • Video motion detection, manual trigger, periodical trigger, system boot, recording notification, camera tampering detection
    Alarm Events
    • Event notification using HTTP, SMTP, FTP and NAS server
    • File upload via HTTP, SMTP, FTP and NAS server
    Connectors
    • RJ-45 for Network/PoE connection
    LED Indicator
    • System power and status indicator
    Power input
    • DC12V
    • IEEE 802.3af PoE Class 3
    Power consumption
    • Max: 6.5 W (DC12V)
    • Max: 7.5 W (PoE)
    Dimensions
    • Ø: 128 mm x 98 mm
    Weight
    • Net: 435 g
    Safety Certifications
    • CE C-Tick FCC ( Class B ) LVD VCCI
    Operating Temperature
    • Starting Temperature: 0°C ~ 50°C (32°F~122°F)
    • Working Temperature: -10°C ~ 50°C (14°F ~ 122°F)
    Warranty
    • 24 Months
    Operating System
    • Microsoft Windows 7 / Vista / XP / 2000
    Browser
    • Mozilla Firefox 7 - 10 ( Streaming only )
    • Internet Explorer 7/8/9
    Other Players
    • VLC: 1.1.11
    • QuickTime: 7 or above
    Datasheets Download
    User's Manuals Download

    What's included
