FD8167

Feature

  • 2-Megapixel CMOS Sensor
  • 30 fps @ 1920x1080
  • 2.8 ~ 12 mm Vari-focal, P-iris Lens
  • Removable IR-cut Filter for Day & Night Function
  • Built-in IR Illuminators, Effective up to 30 Meters
  • Real-time H.264, and MJPEG Compression
  • Two-way Audio
  • WDR Enhancement for Unparalleled Visibility in Extremely Bright and Dark Environments
  • Smart IR Technology to Avoid Overexposure
  • 3D Noise Reduction
  • PIR
  • Support Installation with AM-712 Conduit Box
  • SNV (Supreme Night Visibility)
  • VIVOTEK FD8167 is a stylish, indoor-style network camera designed for diverse indoor applications. Equipped with a 2MP sensor enabling viewing resolution of 1920x1080 at a smooth 30 fps, the FD8167 is an all-in-one indoor camera capable of capturing high quality and high resolution video up to 2 Megapixel, even in low light environment. Providing such a polished image quality, FD8167 is also designed with VIVOTEK Smart Stream, 3DNR to save notable bandwidth for users.

    To emphasize the image quality, FD8167 also comes with a P-iris lens, which controls the iris with extreme precision with its built-in stepper motor. By using software controls, the lens maintains the iris opening at an optimal level at all times, resulting in superior sharpness and depth of field as well as image quality.

    CPU
    • Multimedia SoC (System-on-Chip)
    Flash
    • 128 MB
    RAM
    • 256 MB
    Image sensor
    • 1/2.8" progressive CMOS
    Maximum Resolution
    • 1920x1080
    Lens Type
    • Vari-focal
    Focal Length
    • f = 2.8 ~ 12mm
    Aperture
    • F1.8~F2.85
    Auto-iris
    • P-Iris
    Field of View
    • 35° ~ 105° (horizontal)
    • 20°~ 54° (vertical)
    • 41°~ 123° (diagonal)
    Shutter Time
    • 1/5 sec. to 1/32,000 sec.
    WDR Techonolgy
    • WDR Enhanced
    Day & Night
    • Removeable IR-cut filter for day & night function
    Minimum Illumination
    • 0.06 Lux @ F1.8
    • 0.001 Lux @ F1.8
    Pan / Tilt / Zoom
    • ePTZ
    • 48x digital zoom ( 4x on IE plug-in, 12x built-in )
    IR Illuminators
    • Built-in illuminators, effect up to 30 meters with Smart IR
    • IR LED*6
    On-board Storage
    • MicroSD/SDHC/SDXC card slot
    Compression
    • H.264 & MJPEG
    Maximum Frame Rate
    • 30 fps @ 1920x1080 in both compression
    Maximum Streams
    • 3 simultaneous streams
    S/N Ratio
    • Above 62 dB
    Dynamic Range
    • 60 dB
    Video Streaming
    • Adjustable resolution, quality and bitrate
    Image Settings
    • Adjustable image size, quality and bit rate, Time stamp, text overlay, flip & mirror, Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks,Scheduled profile settings, Seamless recording, smart stream, 3D Noise Reduction
    Audio Capability
    • Audio input/output (full duplex)
    Audio Compression
    • G.711
    • G.726
    Interface
    • Built-in Microphone
    • External line output
    Users
    • Live viewing for up to 10 clients
    Protocols
    • IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP
    Interface
    • 10Base-T/100 BaseTX Ethernet (RJ-45)
    ONVIF
    • Supported, specification available at www.onvif.org
    Video Motion Detection
    • Triple-window video motion detection
    Alarm Triggers
    • Video motion detection, manual trigger, periodical trigger, system boot, recording notification, camera tampering detection
    Alarm Events
    • Event notification using HTTP, SMTP, FTP and NAS server
    • File upload via HTTP, SMTP, FTP and NAS server
    Smart Focus System
    • Manual focus
    Connectors
    • RJ-45 for Network/PoE connection
    • Audio output
    • DC 12V power input
    • Digital input*1
    • Digital output*1
    LED Indicator
    • System power and status indicator
    Power input
    • DC12V
    • IEEE 802.3af PoE Class 3
    Power consumption
    • Max: 8.6 W (DC12V)
    • Max: 9.7 W (PoE)
    Dimensions
    • Ø: 135 x 102 mm
    Weight
    • Net: 512 g
    Safety Certifications
    • CE, LVD, FCC Class B, VCCI, C-Tick, UL
    Operating Temperature
    • Starting Temperature: -10°C ~ 50°C (14°F~122°F)
    • Working Temperature: -20°C ~ 50°C (-4°F ~ 122°F)
    Warranty
    • 36 Months
    Operating System
    • Microsoft Windows 7 / Vista / XP / 2000
    Browser
    • Mozilla Firefox 7 - 10 ( Streaming only )
    • Internet Explorer 7/8/9/10
    Other Players
    • VLC: 1.1.11
    • QuickTime: 7 or above
    Datasheets Download
    User's Manuals Download

    What's included
